In the settings view, you can select the measuring direction, define the cable measurement point interval and nearest surface point. You can also select the measuring mode as well as define warning settings for inclination and hole deviation, and change the language of the operating system. To access this view, click the Settings button in the home menu.
Figure 1. Measuring settings tab
The measuring mode can be defined under the Compass section:
-
Gyro only for magnetic conditions. The Operator sets the collar heading for each hole. The Gyro only mode is sensitive to correct working methods.Note: Azimuth information on vertical and horizontal holes is limited.
- Magnetometer assisted gyro measurement to lower the magnetic influence. In this mode, the shape of the borehole is measure with gyro, whereas the collar heading is measured with magnetometer. The Magnetometer assisted gyro mode is sensitive to correct working methods.
- Combination of gyro and magnetometer for best accuracy and most robust results. Suitable for all hole directions.
Figure 2. Warning level tab
Figure 3. General settings tab
